Configuration

Platforms and sensors.

To work with live video streams, you must first configure them. In general, the server works with a logical entity called a Platform such as a plane, drone, or car, that can carry multiple Sensors (video cameras) or other data sources. The operator configures the platforms.yml file to specify the existing platforms and network topology.

When you record the streams, it becomes a mission, which includes live feeds, recordings, and descriptive metadata. Until recording is active, it's simply a video feed — the mission may or may not have started yet.

The StanagOnDemand server works with Stanag streams that come as UDP multicast streams. If you have unicast source streams, you can use a stream recaster for unicast-to-multicast recasting.

Basic platform configuration

Let's use an example to show the configuration file that defines two UAV platforms (with names UAV_1 and UAV_2)

The first UAV has four video sensors:

• EO/IR sensor with the stream coming from udp://227.1.1.1:30120
• Tail camera sensor with the stream coming from udp://227.1.1.2:30122
• Operator screen capture sensor with the stream coming from udp://227.1.1.3:30123
• Radar capture sensor with the stream coming from udp://227.1.1.4:30124

Note that the Radar sensor has the active parameter set to false (active: false), so this sensor is not monitored. Set it to true to enable monitoring.

The second UAV has only one sensor:

• EO/IR sensor with the stream coming from udp://228.1.1.1:1234

If you have only one UAV (platform) to monitor, there should be only one platform on the list.

platforms:
# First platform
  - name: UAV_1
    active: true
    description: First platform
    type: Plane
    sensors:
      - name: EO/IR
        description: EO/IR sensor
        active: true
        type: video
        url: udp://227.1.1.1:30120

      - name: Tail
        description: Tail camera
        active: true
        type: video
        url: udp://227.1.1.2:30122

      - name: Operator
        description: Operator screen
        active: true
        type: video
        url: udp://227.1.1.3:30123

      - name: Radar
        description: Radar
        active: false
        type: video
        url: udp://227.1.1.4:30124

# Second platform
  - name: UAV_2
    active: true
    description: Second platform
    type: Plane
    sensors:
      - name: EO/IR
        active: true
        type: video
        url: udp://228.1.1.1:1234

Note. If you have to select the specific network interface, use add ?localaddr= to the url:

udp://227.1.1.1:30120?localaddr=192.168.1.28

Allowed platform types:

• Plane
• Helicopter
• Quadcopter
• Camera
• ROV
• Diver

Configuring live video

The live video preview is provided by different services:

• Live preview - stsupervisor
• Live (WebRtc) - stanag2webrtc
• DVR - stserver or stvideo-server

Note: WebRTC requires a secure HTTPS connection for proper operation in browsers. Therefore, STServer must be deployed behind a reverse proxy configured with HTTPS (for example, Nginx) when serving clients over the internet. This ensures secure signaling and media transport setup. The only exceptions to this requirement are when STServer is accessed from localhost or within a trusted local network, where HTTP connections are also permitted. In all other cases, HTTPS must be enforced to ensure compatibility and security.

stanag2webrtc service in docker-compose.yml

  stanag2webrtc:
    image: impleo/stanag2webrtc:3.0.1
    container_name: stanag2webrtc
    restart: always
    network_mode: host
    volumes:
      - ./data/:/app/data/
    environment:
      ADDR: 0.0.0.0:8081
      WEBRTC_SERVICE: "stanag2webrtcwhep"
    #  WEBRTC_LOOPBACK_ICE_CANDIDATE: true  # Use loopback ICE candidate (if local access is required). If true, the server will use a loopback ICE candidate
    #  WEBRTC_FULL_ICE: true  # If true, the server will use full ICE (not ICE-Lite) for WebRTC connections
      KLV_SAMPLING: 300

More on stanag2webrtc service configuration

You can override the default parameters for each channel by adding a live section to the sensor configuration. For example, if you have a video that can be played directly in the browser using the H.264 codec, enabling video pass-through by setting the videoPassthrough parameter to true is recommended to preserve the original video quality and minimize CPU usage.

# Platforms
platforms:
# First platform
  - name: UAV_1
    active: true
    description: First platform
    type: Plane
    sensors:
        - name: EO
          description: EO/IR sensor
          active: true
          type: video
          url: udp://227.1.1.1:30120
          live:
            videoPassthrough: true

Alternatively, if you want to set specific video bitrate, resolution and codec, you can use the videoResolution, videoBitrate and videoCodec parameters.

# Platforms
platforms:
# First platform
  - name: UAV_1
    active: true
    description: First platform
    type: Plane
    sensors:
      - name: EO
        description: EO/IR sensor
        active: true
        type: video
        url: udp://227.1.1.1:30120
        live:
          streams:
            - id:      main    # layer name (used as Simulcast-Layer)
              codec:   vp8     # h264 / h265 / vp8 / vp9 /
              resolution:
                width: 1280
                height: 720
              framerate: 30
              bitrate: 2000
